Various methodologies are used in the production of Pacific cupped oysters, relating to the source of seed supply, the environmental conditions pertaining in different regions and the type of product marketed, whether oysters for the half-shell trade or for meat extraction. Differences in approach are highlighted below with emphasis on seed supply from hatcheries.
Seed supply
Where a supply of natural spat is abundant and reliable, oyster growers set out collectors in the wild to secure their own seed supply, independent of hatcheries. Much of the global supply of spat is obtained from wild seed capture, using a wide variety of settlement materials (cultch) hanging in suspension from longlines and rafts. However, other commercial units operate hatcheries, as described below.
Broodstock
Broodstock for hatchery use is usually obtained from a commercial unit's own sea-based growout facility and is from selected stock maintained in the best possible conditions. Since the sex of adults is not known, groups of adults are obtained at regular intervals from winter through to the natural spawning season. They are held in separate flow-through tanks supplied with cultured algae supplemented seawater at 20–22 °C and salinity within the range 25–32‰. During the winter months, when adults are sexually undeveloped, about six weeks of hatchery conditioning is required to initiate gametogenesis and mature the gametes. A progressively shorter period applies as ambient sea temperature increases towards the spawning season. Adults containing ripe gametes can be spawned by thermal shock treatment but most commonly they are opened and the gametes 'stripped' from the gonads with Pasteur pipettes, a procedure that produces good results. Ripe females of 70–100 g live weight will yield in excess of 50–80 million eggs. For production purposes, the eggs of six or more females are fertilized with small samples of sperm from a similar number of males. Development from the fertilized egg to the fully shelled prodissoconch I (D-larva) stage takes place in large volume tanks filled with finely filtered – and often UV-treated – seawater at 25–28 °C and 25–32‰. Tanks are not aerated and no food is added during early development, which takes approximately 24 hours. Much of global hatchery output now focuses on the production of triploids. Ploidy manipulation, generally by temperature shock, takes place shortly after fertilization although the most recent trend is to cross tetraploids with diploids, which guarantees 100 percent triploid offspring.
Larval and post-larval culture
Larvae are grown in either static water or flow-through tank systems through to the pelagic veliger stage, which lasts 14 to 18 days at 25–28 °C. Optimum salinity is between 20 and 25‰. Initial density is about 20 000 D-larvae/litre and is reduced to about 5 000/litre as development proceeds through natural mortality and selective grading at water changes, which take place three or four times a week for static water tank systems. The object is to retain only the faster growing, healthier larvae as settlement and metamorphosis approaches. Larvae are fed cultured algae. Early stage veligers (<120 µm shell length) are supplied with daily rations of
Isochrysis galbana or
Pavlova lutherii, together with a small diatom such as
Chaetoceros calcitrans or
Thalassiosira pseudonana. The diet of later stage larvae consists of the same species, supplemented with one or other of the various species of the larger green flagellate,
Tetraselmis. When larvae are close to settlement, darkly pigmented 'eye-spots' develop, which are clearly visible through the transparent shell valves. A foot also develops at this stage. At this time, settlement substrate is placed in the tanks for the larvae to explore and attach to. Materials such as slightly roughened, black PVC sheets, fluted PVC pipes, shells or shell particles are used as settlement surfaces. Alternatively, mature larvae may be packed and shipped to oyster growers to set themselves and grow to market size at sites often at great distance from the hatchery. The latter is the method of choice on the Pacific coast of North America and the process is referred to as remote setting.
In many other parts of the world, hatcheries set and grow the resulting juveniles (spat) to a few millimetres (between 3–5 mm) in closely controlled conditions within the hatchery facility. This phase of production is usually accomplished in large volume tank systems with partial daily water replacement, in which the juveniles are held as fluidised beds in containers in a process referred to as upwelling culture. Rations of high nutritional value algae from hatchery culture or from algae bloomed in adjacent outdoor tanks or ponds are supplied continuously to promote rapid growth. Once grown to the required size the spat are either transferred to the hatchery's own outdoor nursery systems or are packed and sold to oyster growers.
Nursery
Hatcheries frequently operate either sea-based or land-based nurseries in which spat are grown from as small as 1 mm length to 12–15 mm. Densities may be as high as 100 kg/m³ water flow in highly productive areas. This method is adopted to reduce mortality in small spat, which may occur if they are transferred directly to sea-based grow-out. Sea-based nurseries are generally upwelling systems mounted on barges or rafts and are located in warmer, more productive estuarine environments. Such containment minimizes risk of losses through predation. Upwelling methodology is also widely used in land-based nurseries, which may be mounted on barges in salt water ponds or in on-land tank systems supplied with algae-rich water pumped from ponds. The ponds may be naturally productive or be enriched with artificial or natural fertilizers. In the case of remote setting, where spat are set on bagged shell cultch, shell strings or plastic materials, the tanks used to set the larvae are also used to grow the resulting spat for a few days or more. This is prior to the set cultch being deployed in some form of protective culture (either intertidally with mesh or canvas covers or sub-tidally on racks or in suspension) to minimize predation losses. Wild caught spat is handled in a similar way.
Yields of 10–15 mm seed for grow-out can reach 3 tonnes/ha in upwelling nurseries supplied from fertilized ponds.
Ongrowing techniques
Grow-out is almost entirely sea-based. A variety of bottom, off-bottom and suspended culture methods are used, depending on the environment (e.g. tidal range, shelter, water depth on leases, water exchange rates in bays and estuarine inlets, the nature of substrates, etc.) and tradition.
Growth is rapid between 15–25 °C and at salinities between 25 and 32‰. It is dependent on the rate of replenishment of the natural phytoplankton food supply. Pacific cupped oysters will take from 18-30 months to reach a market size of 70–100 g live weight (shell-on). Yields from extensive lease areas (covering thousands of hectares), which are used for all aspects of grow-out, including seed collection, the nursery and growing phases, and for hardening oysters prior to harvest, can yield 25 tonnes/ha/yr. Much greater yields (>70 tonnes/ha/yr) can be obtained from well spatially separated, small area leases.
Bottom culture
Seed can be sown on suitably firm intertidal or sub-tidal ground, which may be hardened by the pre-application of shell or gravel, at densities of 200–400/m² when 1 to 2 g live weight, with predator-proof protection (fences or net covers). Alternatively, they can be sown without protection at ~200/m² when 10 g live weight. The object is to sow at densities that will require no further husbandry until the oysters reach marketable size.
Off-bottom culture
Seed are contained in mesh bags or perforated plastic trays of various types attached by rope or rubber bands to wood frame or rebar steel trestles on suitable ground in the low intertidal zone. Such systems are sometimes located sub-tidally but this adds to handling costs. Off-bottom culture may be used for the intermediate nursery phase of growth or as a method to grow product to market size. 10–15 mm seed can be stocked at 1 000–2 000 per 0.25 or 0.5 m² base area trays and need regular maintenance and servicing to transfer at lower density to clean bags/trays of increasing mesh size as they grow. Growth rate slows substantially once the biomass of oysters exceeds 5 kg/m² tray area in reasonably productive areas.
Suspended culture
Three-dimensional containment units are used in hanging culture, which is from longlines (most commonly) or from rafts. The units can be strings or wires of shells to which spat have attached, or they can be series of nets, mesh bags or plastic trays strung together and suspended vertically from the horizontal lines or rafts. This form of culture is used in deeper waters and the same stock densities per net or tray apply as for off-bottom methods. Care needs to be taken to sink units to water depths where fouling organisms are less prevalent and to avoid them touching the bottom at low water. Regular maintenance and servicing is required, to transfer growing oysters at lower density to clean nets/trays of increasing mesh size as they grow.
Floating culture
Wood frame trays with mesh bases or perforated plastic trays provided with buoyancy collars (styrofoam) are used in some locations for earlier stages in the growth of seed. The tops of such units need to be covered with a canvas or tightly woven mesh to exclude light.
Hardening
Pacific oysters grown in suspended culture are commonly 'hardened' for a period of up to three or four months prior to harvesting. The process of hardening allows daily periods of exposure to air and generally takes place in the intertidal zone or in shallow water where tidal range is sufficient. Aerially exposed oysters have higher meat content and better keeping qualities once harvested.
Harvesting techniques
Oysters are usually harvested at >75 mm shell length when 70–100+ g live weight. Harvesting from bottom culture is by hand raking and picking or by dredges when intertidal beds are submerged, or by dredging sub-tidal beds. Marketable oysters grown in off-bottom rack culture or in trays or nets suspended from longlines are harvested from small boats or self-propelled barges, which are often equipped with mechanical washing and grading machinery when the product is destined for the half shell trade. When grown in areas where Paralytic Shellfish Poison (PSP), Diarrhoeic Shellfish Poison (DSP) and other neurotoxins from harmful algal blooms may be present at certain times of the year, harvesting may be halted during such occurrences. Oysters are not usually harvested for a period of two or three months following spawning, for reasons of poor meat quality.
Handling and processing
Smaller individuals may be sold as speciality 'cocktail' oysters. They are either sold live in shell or are shucked and processed frozen, smoked and canned in oil, dried, extracted for oyster sauce, or prepared as other value-added products.
Oysters grown in faecal coliform-free waters require minimal processing. They are washed and graded for size and shape and, if from bottom culture, may be held in tanks in a flow of seawater to rid themselves of sand and mud trapped in the mantle cavity. If faecal coliform contaminated, oysters will require a period of depuration in recirculation systems equipped for UV-light or ozone sterilization. Single oysters destined for half shell markets are packed with the cupped valve down in order to conserve mantle cavity water. Shelf life is seven to ten days when properly packed and stored in cool conditions. Vacuum packed, value-added products in the half shell have been marketed in Europe with some success, although the bulk of trade is for the live product. In many other countries harvested oysters are transported to shucking plants for meat extraction, bottling, canning or freezing, or are used in the preparation of products such as oyster sauces. Processing is strictly controlled in most countries.
Production costs
Information on production costs is difficult to obtain, not only because the information is proprietary but also because of site specific factors, the diversity of methods used and the widely varying levels of technology employed. Seed supply is generally calculated to be in the vicinity of 20–25 percent of total costs. In developed countries, 3–4 mm hatchery-produced seed is sold at USD 10–15/1 000, while mature larvae for remote setting will cost approximately USD 2/million (ex transport costs). Culturing oysters for the shucked meat trade is less labour and equipment intensive than producing oysters for half shell markets, and bottom culture is less costly than suspended (hanging) culture. Feed does not figure in the cost equation because it is a free resource once seed is transferred to sea-based grow-out. Labour is a major recurring cost and is generally of a seasonal nature.
In contrast to other oysters of importance in commerce, and despite its widespread distribution around the world, few disease problems of major significance have been reported for the Pacific cupped oyster. Of greater concern have been incidences of 'summer mortality' on the Pacific coast of the USA and in France, which appears to be related to post-spawning physiological stress in warm water when oysters are densely crowded. Introductions of Pacific oysters are not thought to have brought pathogens with them that have resulted in catastrophic diseases in indigenous bivalves. However, their transport to some countries for direct relaying in the sea has been inadvertently accompanied by a number of pests and parasites including the Japanese oyster drill,
Ceratostoma inornatum, the oyster flatworm,
Pseudostylochus ostreophagus, and the copepod parasite,
Mytilicola orientalis. Bacterially related diseases of larvae and early juveniles are not uncommon in hatcheries and are most frequently attributed to
Vibrio spp. In this context,
C. gigas larvae are equally as prone to mass mortalities as are the larvae of other bivalve species.
Observed diseases and parasites are summarized in the table below.
In some cases antibiotics and other pharmaceuticals have been used in treatment but their inclusion in this table does not imply an FAO recommendation.
Denman Island Disease |
Mikrocytos mackini |
Protozoan parasite |
– |
Restricted modified culture practices |
Nocardiosis |
Nocardia crassostreae |
Bacterium |
– |
Modified culture practices |
Herpes-type virus disease of C. gigas larvae |
– |
Virus |
– |
None |
Oyster velar virus disease (OVVD) |
– |
Virus |
– |
None known |
